Model:
MX-L302X
Brand:
SMX
Code:
852869
Product Name:
3LCD Projector
Display Panel:
3x0.63"
Light Source:
Lamp: 225W
Zoom/Focus:
Manual
Throw Ratio:
70"@2.1m; 1.48~1.78:1
Brightness:
3500 Lumens
Resolution:
1024x768
Contrast:
15000:1
Input:
VGA, HD MI,Video
Standard Accessaries:
Power cord, VGA cable, Remote control

Product Description

3500 Lumen Education 3LCD Projector 1024x768 15000:1
China Factory with cheap price ODM

Outstanding Performance in a Compact Body

 High Brightness, Contrast ratio

 Brightness  can reach 3500 lumens, This series is completely equipped with 15000:1 ratio, high color display 1.07 Billion. Even in standard daylight classroom & meeting rooms, presentation brightness is guaranteed to deliver vivid moving colors.

 Extra Long life Lamp

 High quality long life lamps. These series delivers well engineered lamp type that could last up to 20,000 hours. Effectively reduce extra maintenance cost on lamp replacements.

 Super-Fast Start Up and shut down

 Zero second Flash start & shut mode kills waiting time and more business matters.

 Power-trip protection safety feature

 The series comes with short circuit protection feature that anticipate unexpected power cut. Given this ability, it protects expensive components boards and lamp safety.

 Vertical Keystone correction

 The Keystone correction feature allow image to merge to scale onto any projector screen.

 Multiple inputs feature

 1 * sets HD MI, 1 * sets VGA inputs, VIDEO input.

 Quick snap lamp & Filter replacement design

 Design with ceiling installation in mind, projector Users without much training could replace the lamp or filter in a snap. Maintenance can be more regular and with ease by any facility officers.

 Compatibility Support

 Projectors is built to mix with its class of equipment. It support PJLINK, CRESTRON-ROOMVIEW, and AMX-DISCOVERY via internet command systems. Its blends into system and work seamlessly with other brands projectors.

 ESD Anti Dusting feature

 Equipped with high efficient electrostatic dusting functions within the projector, it keeps the LCDs and lenses dust free from any environment.


Model	MX-L302X
Panel	LCX080A-(B5 ML/WO) W/O Micro Lens
PJ Lens	F2.1x1.2
Light source	225W Infinity(Lamp)
Lamp Lifetime(H)	10000H(Normal) /20000H(ECO)
Main IC	Pixworks: PW868
Sony IC	CXD3551+CXA3828
Brightness (Type) ( Ansi Lumens )	3500
Brightness （Mini） ( Ansi Lumens )	3300
Power consumption(MAX)	300W
Display Panel	3x0.63”
Display Technology	Liquid Crystal Display
Native Resolution	XGA (1024x768)
Zoom/Focus	Manual
Throw Ratio	70"@2.1m；1.48~1.78：1
Projection Lens	F:2.1~2.25
Projection Lens	f=19.109~22.936mm
Zoom Ratio	1.2x optics
Screen size	0.887~10.899m（30"~300"）
Contrast Ratio(Min)	15000:1 (w/o IRIS)
Noise(dB)@1m	ECO: 31dB
Noise(dB)@1m	Normal: 38dB
Uniformity(Actual Min)	90%
Aspect Ratio	4:3 (Standard)/16:9(Compatible)
Input	VGA*1
	HDMI*1
	Video*1
Control	RS232*1
Control	USB-B*1(for up-grade)
Keystone Correction	V: ±30° (Manual)
Computer Signal Input	VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,Mac,
Video Signal Input	NTSC, NTSC4.43, PAL, SECAM, PAL-M, PAL-N,
Packaging Box Dimensions (WxHxD mm)	442(L) X 386(W) X 195mm(H)
Gross. Weight (KG)	4.5
Standard Accessaries	Power cord, VGA cable, Remote control
